Solar Swimming pool pump
Series No:SSWP-seriesM.O.Q: 20sets
Payment:T/T, L/C, Paypal
Warranty:2years
Feature of Pump
Technology: New generation technology, high speed motor
Rotation: 0 to 7200 frequency change, Synchronous constant speed
Power source: DC and Solar power
Pump motor: Permanent magnetBrushlessDChigh speed and synchronous motor
Frequency: Synchronous and DC frequency change
Motor efficiency: 83-92%
Unit efficiency: 2%-5% higher than the GB
Functionality: Multifunctional and no limit, automatic protection
Shell material: Q304 stainless steel, better than normal Q201.
Warranty: 3year for pump, 1year for the pump controller
Model No.
Head(M)
Flow rate(m3/h)
Size
Pump Length
Pump
Pump
Solar panel
Rated
Max
Rated
Max
Outer
Outlet
Power
Voltage
Power
Voltage
Quan.
SSWP-3-6.0P(M)
3.0
7.0
6.0
9.0
290x390mm
50mm(2")
570mm
plastic
370W
24V DC
300W
36V
2
SSWP-5-13P(M)
5.0
15.0
13.0
17.0
600W
36VDC
150W
18V
6
SSWP-5-18P(M)
5.0
19.0
18.0
21.0
750W
48V DC
300W
36V
4
SSWP-5-24P(M)
5.0
19.0
24.0
28.0
310x450mm
63mm(2.5")
670mm
1000W
72V DC
200W
36V
8
SSWP-6-25P(M)
6.0
19.0
25.0
31.0
1200W
72V DC
300W
36V
6
Impeller
Download:DC Swimming pool pump
